MCP-170
RATINGS


 MCP-170 Maintenance Control Panel can be used for maintenance and precise adjustment with a BS (Base Station) / CCU (Camera Control Unit) or a CSU (Camera Select Unit) connected. 8 cameras (BS/CCU) can be connected to one CSU and 5 CSUs can be controlled by one MCP. Therefore, one MCP can control up to 40 cameras for maintenance and precise adjustment.

  • Traditional Control Conception (ICCP)
  • Direct button Operation
  • Single Cable Connection with Power Supply
  • For control up to 40 Cameras
You want further information?

Feel free to contact us.
Service-Hotline: +49 (0) 2131 1230
E-Mail: broadcast@ikegami.de
Contact Form



up

RATINGS / PERFORMANCE MCP-170
Power Supply Voltage +12 V (+11 V to + 16 V)
Operating Temperature 0° C  to  + 45 °C
Operating Humidity 30 % to 90 %
Dimensions W 182 x H 341 x D 55 mm
Weight Approx. 1.7 kg
